CartonWrap

The pioneer in 3D right-sized packaging

Boxing Solutions

CartonWrap

The automated right-sized solution that builds ready-to-ship boxes around the item, without void fill. Ideal for any vertical.

CMC Cartonwrap

Creates dynamic boxes from either fanfold-fed corrugate, cut sheet feeder or wave line. Boxes are created unique to the product being shipped, eliminating the need to use void fillers and reducing volumes.

TECHNICAL VIDEOS

CMC Cartonwrap

Creates dynamic boxes from either fanfold-fed corrugate, cut sheet feeder or wave line. Boxes are created unique to the product being shipped, eliminating the need to use void fillers and reducing volumes.

Unique Box Design

Each box is built to protect what’s inside. Double layer of corrugated cardboard material on two sides. Bumper edges for corner protection.

EASY TO OPEN

RESEALABLE

READY FOR RETURNS

Highlights

No void Fill

A right-sized box is directly built around the order.

NO DATA DEPENDENCY

PROTECTIVE BOX DESIGN

Technical Specifications

FANFOLD SPECSfrom 600 mm to 1200 mmCUT SHEET SPECSMAX W 1200 x L 2300 mmWAVE LINE SPECSMAX REEL WIDTH: 1200 mmMINIMUM BOXW 240 x L 150 x H 30  mmMAXIMUM BOXW 600 x L 350 x H 200 mmMAXIMUM MECHANICAL SPEED1000 boxes/hourMAX PRODUCT WEIGHT10 Kg

22,9m x 7,3m

DIMENSIONS / FOOTPRINT

Ancillary
Equipment

  • Up to 6 sides reading on product input conveyor
  • Up to 4 cardboard input channels
  • Cut sheet feeder
  • Invoice printer
  • Selective enclosure feeders
  • Additional Print&Apply Labelers
  • Multi Hazmat Label applicators
  • Check weigher
  • Easy opening & reseal
  • Dashboard
  • Camlogger
  • Packvertizing
  • RFID Reader
  • Sorting system
  • Trimming shredder

Discover More

DISCOVER THE FULL RANGE

CASE STUDIES

View All
